EQ-6-S8

Sold per piece.

The Earthquake EQ line of Maximum Musical Output drivers are specifically designed to provide smooth, low-distortion mid-range/mid-bass output for the highest quality sound reinforcement applications.

Because of their relatively high resonance and very low Qts values, the EQ line can be mounted in small enclosures while maintaining a smooth, peak-free response.
£0.00
£0.00

Specifications
Model Name: EQ-6-S8
EAN:  0168975910158

  • Frequency Response: 377Hz - 5kHz
  • MAX Power: 60W
  • Nominal Impedance: 8 ohm
  • Sensitivity: 93dB to 110dB
  • Woofer Size: 6.5" Midbass

Dimensions:

  • Diameter: 169.5 mm
  • Cut out hole: 142 mm
  • Mounting Depth: 66.9 mm

Parameters:

  • Fs: 377 Hz
  • Qms: 4.122
  • Qes: 1.72
  • Qts: 1.214
  • Xmax: 0.2mm

Box Dimensions: 10 × 18 × 18 cm
Box Weight: 2.375 kg

  • 8-Ohm impedance
  • Edge-wound aluminum bobbin voice coils
  • Enhanced sound quality
  • Heavy duty ferrite magnets
  • High efficiency / sensitivity
  • Low harmonic distortion
  • Max output
  • Multi roll cloth surround
  • New longer lasting low mass cone
  • Not Vented T-Yoke
  • Sealed Basket
  • Stamped steel basket with jet-black finish
